Selection and technical requirements of the bending strength testing machine for ceramic specimens

   The model of the ceramic sample bending strength testing machine is: CMT-10. This testing machine can be used for the bending strength test of ceramic materials. After configuring other test accessories, it can also be used for metal sample, plastic, rubber and other materials tensile, compression, shear, peeling and other static mechanical performance tests, so it is also called universal testing machine. Test parameters such as ReH, ReL, Rp0.2, Fm, Rt0.5, Rt0.6, Rt0.65, Rt0.7, Rm, E can be automatically obtained, and according to GB, ISO, DIN, ASTM, JIS and other domestic and international standards for testing and provide data..

   The ceramic specimen bending strength testing machine developed and manufactured by Liangong is equipped with a DSC-10 full-digital closed-loop control and measurement system to achieve dedicated closed-loop control of displacement, deformation, and speed; in addition, it also has two-level software and hardware protection functions to achieve a variety of safety protection methods for the testing machine such as overload, overcurrent, overvoltage, undervoltage, overspeed, limit position, etc.; the cost performance is super high, and you can choose with confidence.

   Technical requirements of ceramic sample bending strength testing machine:

1. Maximum test force: 10kN

2. Test force measurement range: 0.4%~100%FS (full scale)

3. Test force indication error: within ±0.5% of indicated value

4. Test force resolution: ±1/300000 of test force

The whole process is not divided into files, and the whole resolution remains unchanged

5. Deformation measurement range: 0.2%~100%FS

6. Deformation indication error: within ±0.5% of indication

7. Deformation resolution: 1/300000 of deformation

8. Displacement indication error: within ±0.5% of indication

9. Displacement resolution: 0.025μm

10. Adjustable range of displacement rate: 0.001~500mm/min

11. Effective test width: 400mm

12. Test space: 400mm

13. The overall dimensions of the host (length × width × height): (690 × 470 × 1150) mm

14. Host weight: about 200Kg

15. Power supply: 220V, 50Hz, 0.4kW
